Connection size & installation fit
This listing is for the 28 mm model. Other connection sizes or types require a separate enquiry and are not included with this item.
Pipe connection size is not the overall product size. For a dimensioned drawing or tight-space installation, email sales@rockensupplygroup.co.uk.
Product Description
The Antifreeze Valve is designed to provide automatic frost protection for air source heat pump (ASHP) systems and outdoor heating circuits.
When the water temperature falls to approximately 3°C, the valve automatically opens to discharge water from the system, helping to reduce the risk of freezing and potential damage to heat pumps, pipework and associated components. Once the temperature rises to approximately 4°C, the valve automatically closes.
Manufactured from high-quality CW617N brass, the valve offers durable and reliable performance in demanding outdoor heating applications. Its fully mechanical operation requires no external power supply, providing dependable freeze protection even during a power failure.
This listing is the 28 mm model. Contact KIVO to enquire about other sizes or connection types.
Key Features
- Automatic freeze protection for air source heat pump systems
- Opens automatically at approximately 3°C
- Automatically closes when temperature rises to approximately 4°C
- No electricity or external power supply required
- Helps protect heat pumps, pipework and outdoor heating circuits from frost damage
- Manufactured from durable CW617N brass
- Suitable for exposed outdoor heating installations
- Compact design for straightforward installation
- 28 mm connection size for this listing
- Confirm connection compatibility before installation
Technical Specifications
| Specification | Details |
|---|---|
| Material | CW617N Brass |
| Maximum Working Pressure | 10 bar |
| Working Temperature | 0°C to 90°C |
| Ambient Temperature | -30°C to +60°C |
| Opening Temperature | 3°C |
| Closing Temperature | 4°C |
| Temperature Accuracy | ±1°C |
| Connection Type | Confirm the supplied fitting type before installation |
| Available Sizes | 28 mm (this listing) |
| Power Supply | Not Required |
| Application | Air Source Heat Pumps / Outdoor Heating Systems |
Applications
Ideal for use with:
- Air source heat pump systems
- Outdoor heating pipework
- ASHP flow and return circuits
- Domestic heating installations
- Commercial heat pump systems
- Exposed heating pipework requiring frost protection
Why Use an Antifreeze Valve?
Air source heat pump systems often include pipework and components installed outdoors. During freezing conditions, stagnant water within exposed sections of the system can freeze and potentially damage pipework, valves or heat pump components.
The antifreeze valve provides a simple mechanical safeguard, automatically responding to low water temperatures without relying on electricity, sensors or electronic controls.
